Lashing and Lifting Material
Types of Lifting Beams
Low Headroom
Manufactured with two alloy swivel latch hooks standard; multiple latch hooks, eye latch hooks, and shackle plates also available. Excellent for lifting applications where limited headroom is an issue. Available in both standard and heavy duty fabrications. Standard is designed to safely lift one-half ton to five ton; heavy duty is approved for lifting 7.5 to 20 ton.
Ultra-Low Headroom
A hoist hook nested within the beam provides added space in situations where minimal headroom is available during a lift. This lifting beam design features spacers to ensure hook remains centered. Standard model features standard alloy swivel latch hooks; additional hardware options available by request.
Economy Adjustable with Shackles
Adjustable design makes adjusting unbalanced loads fast and simple. Manufactured with shackle connections on the bottom. A low profile top connects to loads even in lower profile situations. Custom connection hardware including swivel hooks, eye hooks, and other are available per special order.
Economy Fixed with Shackles
Standard fixed style beam combines shackles on the bottom of each end and an oversized lifting eye on top for quick and easy attachments. Excellent for general warehouse and jobsite use.
Adjustable Lifting Beam with Shackles
Shackles on the bottom provide strong and stable connection points, while the adjustable design lets you quickly and easily adjust a load that’s unbalanced. Also available with swivel hooks standard, or with other hardware options by special order.
Adjustable Lifting Beam with Swivel Hooks
Swivel hooks on the bottom provide fast and easy connection points, while the adjustable design lets you adjust loads out of balance. Also available with shackles hooks standard; other hardware options by special order.
Non-Conductive
Non-conductive construction is engineered with natural spark proof insulation, making it excellent for handling large batteries and other similar cargo. Lift lug is painted in safety yellow for increased visibility. Fitted with two shackles on the bottom that adjust to accommodate different widths. Hooks, handles, and other lug connections also available by special order for battery lifting beams.
Basket Lifting Beams
Intended for use with a lifting sling in a basket hitch configuration. Features two sets of low profile, bull-horn style lifting hooks, each designed for a sling with a 2" eye width. Custom options are available by special order.
Twin Hoist Lifting Beams
Two hoist design creates a stable lift for a variety of cargo when lift is with 5 degrees of vertical. Alloy swivel hook on the bottom is standard equipment, but load-bearing swivel hook, eye hook, or other custom configurations also available for this type of hoist beam.
Plate Lifting Beams
Connects to sling with openings on the top of each end; bottom of beam lift is designed with large J-shaped hooks to hold and lift plates.
Container Lifting Beams
Designed for lifting soft-side bulk container or other types of flexible containers with lifting loops/webbing. The H-shaped beam configuration features a oversized lifting eye for fast connections. Built-in lugs on each beam keep the loops or webbing of the container from sliding off or inward and unbalancing the container. Lug spaces accommodate up to 3" wide webbing/loops. Container lifting beams are also known simply as bulk container beams by others in the industry such as Caldwell lifting beams and Grainger.
Small Length with Bale Top
Shorter length, triangle beam with a bale-style top is ideal for balancing and lifting smaller loads. Manufactured with shackles on the bottom for secure and stable connection points.
Small Length with Shackle Top
A solid triangle design offers stability to loads during lifting, while the shackle points on the bottom and top create secure connections. Shackles are standard; also available with a bale-style top. Custom configurations also available by special order.
A spreader bar, also known in the industry as a spreader beam, is designed for use with a sling that connects the lifting machine hook to the ends of the beam. The beam typically has connection points on the underside that hook to the cargo for lifting.
Spreader beams distribute the load across more than just one point, resulting in increased stability. They are excellent for applications where the cargo is too large or heavy to be lifted from one singular connection point.
A spreader beam is also ideal for use in situations where load control is important and/or the lift points are far apart. A spreader beam or bar can also accommodate a sling on each of the bar to lift long, narrow cargo held horizontally.
Because the sling legs lengthen the distance from the hook to the cargo, spreader beams as lifting devices are generally a limited option when there is little headroom clearance.
Types of Spreader Bars
Fixed Spreader Beams
Swivel latch hooks on the bottom combine versatility, quick connections, and a secure lock. Other hardware options are available, as well as custom configurations
Adjustable Spreader Beams
Like a fixed spreader beam, adjustable spreader beams are excellent for supporting long loads during lifts. An adjustable spread model offers additional versatility due to its telescoping design that lengths the device in 1" increments.
1. Lightweight: The design is optimised to provide lightweight Spreader Beams - keeping the weight of the Rigging down can help optimize your crane selection, particularly at a large working radius.
2. Portable: A Spreader Beam that is dismantled can be transported easily – the maximum length struts are usually under 6 metres (20ft). Many of the smaller sizes have components that are light enough to be handled by one person.
3. Custom Options: From custom-length Struts, to custom designed Lifting Rigs – our team of experienced engineers are here to help.
4. Versatile: One Spreader Beam can be re-assembled and used at many different possible spans.
5. Economical: Spreader Beams can be used over and over again for years, for all sorts of applications.
We offer a full line of Lifting Slings in addition to our selection of Rigging Supplies and Hardware.
Hackles
Metal rigging shackles can be used as a link to connect equipment in various hoisting, pulling and lifting applications. Designed in a U shape with lock opening, shackles are extremely versatile and are often used to connect wire rope, chain, nylon or poly rope, or lifting sling hardware products. DM sells a wide variety of shackles in our marine rigging supplies & hardware line, in different sizes and fabrications, including Anchor Shackles, Bow Shackles, Chain Shackles, D Shackles, and Snap Shackles. The type of pin in a shackle can also make a difference in working applications, and include bolt pin type, round pin type, and screw pin.
Turnbuckles
Our wide selection of turnbuckles includes both galvanized and stainless steel varieties, both of which are ideal for weather resistance. Different fittings will serve various purposes and we offer a range of marine rigging hardware items in our turnbuckles category. We also carry different sizes of each style.
Blocks & Pulleys
Blocks and pulleys are common lifting mechanisms in the rigging industry as they can reduce the amount of force required to lift an abnormally heavy object. We offer a full line of finished and stainless steel snatch blocks, square blocks, single and double pulleys, swivel block and many more lifting and rigging hardware supply products that can be used with rope and shock cord.
Eye Bolts
Eye bolts are essential as a riggers supply as they are ideal for providing an anchor point for many rigging applications. DM carries a variety of eye bolts, including straight eyebolts for straight line applications and shoulder eye bolts for any angular connections.
Rigging Hooks
Capacity and fabrication are the most important indicators of hooks for rigging. Design of the hook is also important. Our selection includes hooks with latches, clevis hooks, eye grab, swivel eye, fixed eye, self-locking hooks and snap hooks.
Stainless Steel Nuts
Stainless steel rigging hardware nuts come in a wide variety of styles and sizes for different rigging applications, such as lifting eye nuts, dome nuts, hex nuts, wing nuts, and ball ends. All of our stainless steel nuts (except wing nuts) are type 316 stainless steel, which is considered “marine grade” stainless steel and ideal for marine applications such as sailboat rigging. Hardware of 316 stainless steel type generally is available in both LH and RH thread.
Wire Rope & Accessories (Clips & Thimbles & Sleeves/Stops)
Wire rope comes in a variety of styles and strengths. DM offers bright wire rope, stainless steel rope and galvanized wire rope, all in 6x19 and 6x37 configurations. Common wire rope accessories for rigging include wire rope clips (for clamping loose ends of wire rope), wire rope thimbles (which protect the eye of a wire rope), and sleeves and stops to terminate the ends of wire cable and rope. In addition to wire rope and wire rope accessories, we also carry a full line of nylon strap and nylon strap hardware.
